PROSOCO R-Guard Cat 5
Price range: $655.00 through $14,105.52
PROSOCO’s R-Guard Cat 5 is a primary air barrier that’s applied with a sprayer or roller to above-grade structural surfaces prepared with Joint & Seam Filler and FastFlash. Cat 5 produces a highly durable, seamless, elastomeric weatherproofing membrane on exterior sheathing, CMU backup walls, and precast concrete. Proven to prevent water and air penetration of the building envelope in conditions ranging from everyday to the 155-mph winds of a Category 5 hurricane.
Description
TECHNICAL DATA
- SHELF LIFEÂ 1 year in tightly sealed, unopened container
- VOC CONTENTÂ <30 g/L
- FORMÂ Viscous liquid, mild odor light brown color
- PHÂ Not-applicable
- COVERAGE RATEÂ Exterior Gypsum Board, OSB and Plywood: 50-100 sq.ft. per gallon, CMU: 50-80 sq.ft. per gallon
- FREEZE POINTÂ Not-applicable
- FLASH POINT >200° F (>93° C)
- TOTAL SOLIDSÂ 99%
- WT/GALÂ 11.3 lbs
- AVAILABLE SIZESÂ 5-gallon
- Passive House High-performance building supply
PROSOCO Cat 5 is a single-component, silyl-terminated polymer (STP) that’s applied with a sprayer or roller to produce a highly durable, seamless, elastomeric weatherproofing membrane on exterior sheathing, CMU back-up walls, and pre-cast concrete. Cat 5 is proven to prevent water and air penetration of the building envelope in conditions ranging from everyday weather to the drenching rains and 155-mph winds of a Category 5 hurricane.
Use Cat 5 as the primary air barrier over above-grade structural surfaces prepared with Joint & Seam Filler and FastFlash. Solvent-free. Isocyanate-free. Phthalate-free. Complies with all VOC regulations.
Files and Downloads
Additional information
| Weight | N/A |
|---|---|
| Size | 5 Gallon |
| Quantity | 1 Unit (5 Gallons), 1 Pallet (24 Units / 120 Gallons) |
| Product Type | Liquid Applied |
| Coverage Area | <100 sq ft |
| Application Process | Roller, Spray |
| Application Type | Liquid-Applied |
| Substrate Adhesion | Concrete/Masonry, Wood |
| Vapor Permeability | Class 4 – Permeable |
| Weather Tight | Yes |
| Air Tightness | Non-permeable |
| Interior/Exterior | Exterior |
| Certifications | Declare (ILFI), LEED, Red List Approved (ILFI) |
| VOC Content (g/L) | <30 g/L |
| Brand | Prosoco |
