Thermo Wood Window
Zola Thermo Wood™ is a classic choice for Source 2050 homes. With R-11 glass standard in an industry-leading 18mm spacer thickness, Thermo Wood can be offered in extremely large sizes.
[s2050_window_upload_form]
THERMO WOOD
The classic look of timber windows and doors, with no aluminum cladding on the exterior. Featuring Zola's standard R11, triple-pane glazing, and triple air seals, Thermo Wood aligns high-performance with the warm appearance of timber throughout. A laminated, warp-resistant, solid timer construction frame. Triple compression air seals for optimal air tightness. High-performance building supply
TIMBER & FINISH OPTIONS
Timbers available: finger jointed pine (base timber), Clear Pine, Meranti, European White Oak,
and Larch.
Interior Finish Options: RAL painted timber, or standard set of interior stains.
Exterior Finish Options: RAL painted timber, or standard set of exterior stains.
*Dual stain option is not available.
CONFIGURATIONS AVAILABLE
Fixed
Tilt-turn, Tilt-only, Turn-only, Tilt-first Fixed/Operable combinations French window opening
Inswing and Outswing Terrace Doors Lift-Slide Doors
Inswing and Outswing Entry Doors Breeze Panel Doors
HARDWARE
European multi-point locking system with up to eight locking points on windows and four points on entry doors. Visible hinges are standard but concealed hinges are available.
OPERABLE SIZING
Min frame width = 450mm (17.7”)
Max frame width = 1521mm (59.8”)
Min frame height = 416mm (16”)
Max balcony door height = 2743mm (108”)
Key Specifications
| Property | Specification |
|---|---|
| Brand | Zola |
| Configuration | Breeze Panel, Facade Systems, Fixed, Glass Doors, LiftSlide, Modern Doors, Panel Doors, Tilt, Tilt & Turn |
| Glazing | Double, Triple |
| Max. Frame Height | 108 |
| Max. Frame Width | 59.8 |
| Min. Frame Height | 16 |
| Min. Frame Width | 17.7 |
| PSI-Value (BTU/hr·ft·°F) | 0.02312 |
| R-Value | > 6 |
| U-Value (BTU/h*F*ft) | >0.1 |
