Thermo Clad Window
The Thermo Clad™ line of high-performance windows and doors is Zola’s most popular seller. For many customers, this product line hits the sweet spot in terms of value, performance, and craftsmanship.
[s2050_window_upload_form]
THERMO CLAD
Our most popular, aluminum-cladding timber windows and doors. Featuring multiple cladding profiles for projects ranging from classic to contemporary. All Thermo Clad windows and doors are standard with triple-pane glazing. Using 88mm frames allows for immense spans of glass in both fixed and operable configurations. A laminated, warp-resistant, solid timber construction frame. Triple compression air seals and exterior aluminum rain-screen cladding mounted on rails for ultimate durability and rot resistance. High-performance building supply
TIMBER & FINISH OPTIONS
Timbers available: finger jointed pine (base timber), Clear Pine, Meranti, European White Oak,
and Larch.
Interior Finish Options: RAL painted timber, or standard set of interior stains.
Exterior Finish Options: RAL Standard, RAL FS Premium, Tactile Series, and Anodized options.
CONFIGURATIONS AVAILABLE
Fixed
Tilt-turn, Tilt-only, Turn-only, Tilt-first Fixed/Operable combinations French window opening
Inswing Terrace Doors
Inswing and Outswing Entry Doors Lift-Slide Doors
Breeze Panel Doors (outswing only)
HARDWARE
European multi-point locking system with up to eight locking points on windows and four points on entry doors. Concealed hinges standard.
SIZING
Min frame width = 450mm (17.7”) Min frame height = 402mm (16”)
Key Specifications
| Property | Specification |
|---|---|
| Air Permeability | <1 |
| Brand | Zola |
| Configuration | Awning, Breeze Panel, Facade Systems, Fixed, Glass Doors, LiftSlide, Modern Doors, Outswing, Panel Doors, Tilt, Tilt & Turn |
| Glazing | Double, Quadruple, Triple |
| Min. Frame Height | 16 |
| Min. Frame Width | 17.7 |
| PSI-Value (BTU/hr·ft·°F) | 0.023 |
| R-Value | > 6 |
| U-Value (BTU/h*F*ft) | >0.1 |
