KabSeal Pro Sealing Grommet — Sold by the box
Airtight cable and pipe grommet — flexible rubber sleeve with adhesive flange seals penetrations through the air barrier.
$32.50
Lead Time: 5 business days
Shipping: Quoted after checkout
PARTEL KABSEAL PRO is a flexible airtight grommet for cables, conduits, and small pipes passing through the air barrier — combining a rubber sleeve with a strong adhesive flange.
What it does
The permanently flexible rubber accommodates cable movement and structural settling without losing the seal. The acrylic-adhesive flange bonds the grommet to the membrane or substrate, creating a continuous, durable airtight detail at penetrations that are otherwise the weakest point in the air barrier.
When and where to use it
- Electrical cables and conduits through air barriers
- Plumbing pipes and ventilation ducts
- MVHR penetrations
- Compliant electrical installations per DIN 18015-5
- Internal and external building envelope locations
Key benefits
- phA Passive House certified
- EC1 PLUS Ecolabel
- Operating range -30°C to +100°C
- Tear and UV resistant
- Split release liner for fast install
- Compatible with airtight detailing per Part L and DIN 4108-7
- Permanently flexible — accommodates building movement
Key Specifications
| Property | Specification |
|---|---|
| Hole Size Range | 3.94" – 4.33" (100 – 110 mm), 2× 0.16" – 0.31" (2× 4 – 8 mm), 2× 0.31" – 0.47" (2× 8 – 12 mm), 4.92" – 5.51" (125 – 140 mm), 0.59" – 0.87" (15 – 22 mm), 0.59" – 1.18" (15 – 30 mm), 5.91" – 6.50" (150 – 165 mm), 7.09" – 7.68" (180 – 195 mm), 7.87" – 8.66" (200 – 220 mm), 0.98" – 1.26" (25 – 32 mm), 0.16" – 0.31" (4 – 8 mm), 1.57" – 2.17" (40 – 55 mm), 1.97" – 2.83" (50 – 72 mm), 2.83" – 3.54" (72 – 90 mm), 0.31" – 0.47" (8 – 12 mm), 3.54" – 3.94" (90 – 100 mm) |
| Sleeve Dimensions | 150x150, 230x230, 320x320, 350x350, 400x400 |
