Plinth Thermal Insulation Profile IHP/EPS
The Blaugelb Plinth Thermal Insulation Profile IHP/EPS (integral rigid foam board/expanded rigid polystyrene foam) offers the best possible heat and moisture protection on front and balcony doors made from wood, wood/aluminium, aluminium and plastic. The Blaugelb Plinth Thermal Insulation Profile IHP/EPS is comprised of an EPS rigid foam core and two layers of IHP integral rigid foam board. The integral rigid foam board has IW67 bonding quality and is bonded with an adhesive of D3 quality (EN 204-D3).
Product benefits:
Benefits of plinth thermal insulation using the plinth thermal insulation profile IHP/EPS:
- Effective IHP insulation offering high potential savings
- Plinth thermal insulation permanently eliminates energy weak points on components installed on floor slabs and enhances indoor comfort
- Prevents damage caused by moisture and mould
Benefits of dovetail joints:
- Quick and easy to fit
- Mobile – for workshop or building site use
- No metal fasteners required
- Can be infinitely extended in length and coupled in height
- No waste
- Passive House High-Performance building material
| Surface and cover plate: | on both sides 10mm IHP white |
| Thermal insulation: | EPS perimeter 30kg/m³, intensive expanded rigid polystyrene foam |
| Gluing: | IW67 waterproof D3 (EN204-D3) |
| 50mm thickness: | 10 mm I 30 mm I 10 mm |
| 64mm thickness: | 10 mm I 44 mm I 10 mm |
| 64mm thickness: | 10 mm I 44 mm I 10 mm |
| 68mm thickness: | 10 mm I 48 mm I 10 mm |
| 74mm thickness: | 10 mm I 54 mm I 10 mm |
| Thermal conductivity Uvalue at 50mm: | 0.733 W/m²K |
| Thermal conductivity Uvalue at 64mm: | 0.559 W/m²K |
| Thermal conductivity Uvalue at 66mm: | 0,548 W/m²K |
| Thermal conductivity Uvalue at 68mm: | 0.523 W/m²K |
| Thermal conductivity Uvalue at 74mm: | 0.478 W/m²K |
| Screw withdrawal value:
SPT 4.3×40 at a vertical engagement depth of 17mm |
1,750N |
| Screw withdrawal value:
Frame Screw Fix FK-T30 2×7.5×42 |
3,240N |
| Pressure resistance: | 4,600kg/m |
