Name: FAKRO Flat Roof Deck-Mounted Skylight
SKU: 22262
Availability: InStock

FAKRO Flat Roof Deck-Mounted Skylight

Includes: DXF (Fixed), DXW (Walkable), DMF (Manual), DEF (Electric), and DEF-S (Solar) all triple glazed

Shipping calculated when order is placed. For a free quote including shipping or to inquire about custom sizes, contact us here.

Flat Roof windows by FAKRO are an excellent alternative to vertical windows as they illuminate the interior and provide a sense of privacy. One of the key benefits of these windows is their high thermal performance, which significantly increases comfort and reduces energy use in your home. Natural light not only brings your homes interior to life but is shown to have psychological and physical health benefits. FAKRO flat roof windows are designed with high resistance materials which allow them to maintain their functionality and appearance regardless of intense sunlight, rain, or snow.

FAKRO offers a wide range of windows for flat roofs to meet a variety of customer needs and preferences. Manually and electrically opened versions allow for full control over the airflow, while non-opening models are ideal for rooms where the priority is only to bring in natural light. They stand behind excellent lighting and impeccable aesthetics.

DXF (Fixed) Key Features

Suitable for roofs with a pitch between 2 and 15 degrees.
Exceptional thermal performance with a U-value of 0.22 BTU/h ft² °F.
Triple-pane passive glazing unit DU6 with warm spacers, argon gas, and two low-E coatings. The external glass is tempered, and the internal glass is laminated for enhanced safety.
Impact resistance rated at Class 5 (EN 14351-1).
Frame constructed from multi-chamber PVC profiles insulated with polystyrene for optimal thermal efficiency.
Compatible with various roofing materials, including TPO, PVC, EPDM, and torched down membranes.

DXW (Walkable) Key Features

Compatible with roof pitches from 0° to 15°.
Exceptional thermal insulation with a U-value of 0.22 BTU/h·ft²·°F.
Triple-pane glazing with a U-value of 0.18 BTU/h·ft²·°F, featuring toughened external glass and laminated internal glass for added safety.
Anti-slip surface ensures secure usage.
Frame constructed from multi-chamber PVC profiles filled with insulation material for optimal thermal performance.
Compatible with various roofing materials, including TPO, PVC, EPDM, and torch-on membranes.
Includes termination bars to securely attach roofing membranes to the skylight frame.

DMF (Manual) Key Features

The frame constructed of multi-chamber PVC profiles filled with insulation material.
An abundance of natural light. The specially designed shape of the window profiles features glazing area up to 16%
greater than those of competitors.
Equipped with the DU6 double chamber highly energy-efficient glazing unit. The external glass is toughened and reflects the sun rays while the internal pane is anti-burglary class P2A. Should the pane crack, shards of glass do not pose a danger but remain on the laminate film.
The glazing unit is bonded using advanced manufacturing technologies to produce high durability and impeccable aesthetics.
Very high class B fire resistance (EN 13501-1).
The highest impact resistance class 5 (EN 14351-1).

Opened manually by means of included control rod (86 5/8 in.). The sash tilts 11 7/8 inches.
Windows can be mounted on an additional XRD or XRD/W base with a height of 6 inches to ensure installation in green
or gravel roofs.
Suitable for pitches from 2° – 15°.
If the roof pitch is less than 2° or if it is advisable to increase the installation angle, the XRD/A angular installation base
should be used, which fitted directly beneath the window lifts installation angle by 3 degrees.
The structure of the window enables installation of internal as well as external accessories.
Toughened external glass with lifetime hail resistance warranty.

DEF (Electric) Key Features

The frame constructed of multi-chamber PVC profiles filled with insulation material.
An abundance of natural light. The specially designed shape of the window profiles features glazing area up to 16%
greater than those of competitors.
Equipped with the DU6 double chamber highly energy-efficient glazing unit. The external glass is toughened and reflects the sun rays while the internal pane is anti-burglary class P2A. Should the pane crack, shards of glass do not pose a danger but remain on the laminate film.
The glazing unit is bonded using advanced manufacturing technologies to produce high durability and impeccable aesthetics.
Very high class B fire resistance (EN 13501-1).
The highest impact resistance class 5 (EN 14351-1).
Electrically opened in the wireless Z-Wave system. The kit includes power supply, remote control and rain sensor.
The sash tilts 6 in.
Windows can be mounted on an additional XRD or XRD/W base with a height of 6 in. to ensure installation in green
or gravel roofs.
Suitable for pitches from 2° – 15°.
If the roof pitch is less than 2° or if it is advisable to increase the installation angle, the XRD/A angular installation base
should be used, which fitted directly beneath the window lifts installation angle by 3 degrees.
The structure of the window enables installation of internal as well as external accessories.
Toughened external glass with lifetime hail resistance warranty.

DEF-S (Solar) Key Features

suitable for roof pitches between 2-15 degrees
Triple-glazed DU6 skylight has an R-value of 8.1
perfect solution for passive houses
sound reduction index Rw 34 dB
can be used with roofing products as TPO, PVC, EPDM
single ply or torched down membranes
range of internal and external accessories available
